Paul M Burke

6455074, Sep 24, 2002

Aug 16, 1999

09/375090

Mark A. Tracy - Arlington MA
John D. Herberger - Moore Park CA
Paul A. Burke - Oxnard CA
Paul F. Herbert - Wayland MA

Alkermes Controlled Therapeutics, Inc. - Cambridge MA

A61F 216

424501, 424502, 424426, 42840221, 264 41, 264 43, 264 433

The present invention relates to a polymer-based sustained release device, and methods of forming and using the device for the sustained release of an active agent. The improved method of the invention for forming a polymer-based sustained release device comprises forming a polymer/active agent solution by mixing a polymer, a continuous phase, and an active agent. The continuous phase can comprise one or more polymer solvents, a polymer solvent/polymer non-solvent mixture, or a polymer solvent/active agent non-solvent mixture. When the continuous phase comprises a polymer solvent/active agent non-solvent, the active agent can also be present as a microparticulate rather than in solution. The continuous phase is then removed from the polymer/active agent solution, thereby forming a solid polymer/active agent matrix.

6764472, Jul 20, 2004

Jan 11, 2000

09/481298

Paul F. Burke - Bellingham MA
Kenneth A. Fine - Sharon MA

Bard Access Systems, Inc. - Salt Lake City UT

A61M 3100

60428804

An implantable infusion device includes a lightweight, inert housing which contains an infusate for administration to a patient, and an enclosed, gas-impermeable variable volume chamber which contains a pressure source, such as propellant, mechanical spring, or the like. The variable volume chamber may be in the form of a rigid-walled expandable bellows structure or a nonstretchable flexible bag and is attached to the housing so as not to obstruct the entry port for introduction of infusate. The infusate is delivered from the device via a catheter in response to expansion of the variable volume chamber against the volume of infusate in the housing. A separate bolus injection port is provided which allows infusate to be safely introduced directly into the catheter and overrides the controlled pressure-driven delivery. The lightweight housing may include integrally formed needle stops and suture fastening loops.

7108686, Sep 19, 2006

Jan 11, 2001

10/169821

Paul Burke - Bellingham MA, US
Kenneth A. Fine - Sharon MA, US

Bard Access Systems, Inc. - Salt Lake City UT

A61K 9/22
A61M 37/00
A61M 31/00

6048911, 604131, 604140, 604145, 60428802

An implantable infusion device () includes a lightweight, inert housing () which contains an infusate () for administration to a patient, and an enclosed, gas-impermeable variable volume chamber () which contains a pressure source, such as propellant, mechanical spring, or the like. The variable volume chamber may be in the form of a rigid-walled expandable bellows structure or a nonstretchable flexible bag and is attached to the housing so as not to obstruct the entry port for introduction of infusate. A recharging fluid flow path () is provided adjacent to where the variable volume chamber is attached to the housing. The infusate is delivered from the device via a catheter in response to expansion of the variable volume chamber against the volume of infusate in the housing. A separate bolus injection port () is provided which allows infusate to be safely introduced directly into the catheter and overrides the controlled pressure-driven delivery. The lightweight housing may include integrally formed needle stops ( and ) and suture fastening loops ().

8273058, Sep 25, 2012

Oct 4, 2007

11/906826

Paul F. Burke - Bellingham MA, US
Patrick O'Connor - North Attleboro MA, US

Flowonix Medical Incorporated - Mount Olive NJ

A61M 1/00
A61M 5/00

604151, 604246

An improved implantable valve accumulator pump for the delivery of medication is disclosed. The implantable pump comprises a pressurized drug reservoir. The medication metering assembly comprises a fixed volume accumulator positioned between a pair of valves. The valves alternately open and close to admit medication from the reservoir into the accumulator and to dispense a precise volume pulse to an outlet catheter. In order to improve the pump's accuracy and to increase pumping volume while optimizing the pump's overall size and energy usage a two way diaphragm accumulator is used. The unit can be externally programmed or can be used in a fixed rate configuration that is never programmed but set at the factory or in the current programmable configuration.

8545477, Oct 1, 2013

Oct 22, 2008

12/288659

Paul F. Burke - Bellingham MA, US
Joshua L. Buckman - Newton MA, US
Patrick J. O'Connor - North Attleboro MA, US

Flowonix Medical Incorporated - Mt. Olive NJ

A61M 31/00
A61M 1/00
A61M 37/00
A61M 5/00

604502, 604153, 604141, 604246

Multiple reservoir implantable valve accumulator pump for the delivery of medication, and method of infusate delivery. The apparatus includes at least first and second infusate reservoirs in a common pressure chamber, each in fluid communication with a metering assembly. The metering assembly includes an accumulator that is preferably a fixed volume accumulator having an inlet and an outlet. A first valve is in fluid communication with the first infusate reservoir and an inlet of the accumulator, and a second valve is in fluid communication with the second infusate reservoir and an inlet of the accumulator. An outlet valve is in fluid communication with the outlet of the accumulator. The accumulator can be filled with infusate from the first and second infusate reservoirs sequentially, can be filled from the first infusate reservoir multiple times consecutively, the second infusate reservoir multiple times consecutively, or any combination or permutation thereof.

8551044, Oct 8, 2013

Mar 5, 2008

12/074570

Paul F. Burke - Bellingham MA, US
Joshua L. Buckman - Newton MA, US
Patrick J. O'Connor - North Attleboro MA, US

Flowonix Medical Incorporated - Mt. Olive NJ

A61M 37/00
A61M 1/00
A61M 5/00

604141, 604246, 604153

Multiple reservoir implantable valve accumulator pump for the delivery of medication, and method of infusate delivery. The apparatus includes at least first and second infusate reservoirs in a common pressure chamber, each in fluid communication with a metering assembly. The metering assembly includes an accumulator that is preferably a fixed volume accumulator having an inlet and an outlet. A first valve is in fluid communication with the first infusate reservoir and an inlet of the accumulator, and a second valve is in fluid communication with the second infusate reservoir and an inlet of the accumulator. An outlet valve is in fluid communication with the outlet of the accumulator. The accumulator can be filled with infusate from the first and second infusate reservoirs sequentially, can be filled from the first infusate reservoir multiple times consecutively, the second infusate reservoir multiple times consecutively, or any combination or permutation thereof.

20030031701, Feb 13, 2003

Mar 25, 2002

10/106862

Paul Burke - Medford MA, US

A61F002/00
B27N003/00

424/427000, 264/109000

The present invention includes a method for producing an implantable polymer/drug matrix mass, comprising the steps of (1) forming a polymer solution/drug mixture comprising a polymer dissolved in an organic solvent and a suspended labile drug; (2) removing the solvent from the polymer solution/drug mixture, thereby forming a solid polymer/drug matrix; and (3) mechanically compressing the polymer/drug matrix, thereby forming an implantable polymer/drug matrix mass.

20030035845, Feb 20, 2003

Mar 7, 2002

10/094953

Stephen Zale - Hopkington MA, US
Paul Burke - Medford MA, US
Howard Bernstein - Cambridge MA, US
Avram Brickner - Brookline MA, US

A61K033/00

424/600000

A composition, and methods of forming and using said composition, for the sustained release of non-aggregated, biologically active, erythropoietin (EPO). The sustained release composition of this invention comprises a polymeric matrix of a biocompatible polymer and particles of biologically active, aggregation-stabilized EPO, wherein said particles are dispersed within the biocompatible polymer. The method of the invention for producing a composition for the sustained release of biologically active EPO includes dissolving a biocompatible polymer in a polymer solvent to form a polymer solution, dispersing particles of biologically active, aggregation-stabilized EPO in the polymer solution, and then solidifying the polymer to form a polymeric matrix containing a dispersion of said EPO particles. The method for using a composition of the invention is a method for providing a therapeutically effective blood level of biologically active, non-aggregated erythropoietin in a subject for a sustained period. In this method, a subject is administered an effective dose of the sustained release composition of the present invention.
