Inventors:
Richard C. Johnson - Saint Paul MN
Otto R. Kafer - Saint Paul MN
Mike J. Todd - Rosemount MN
Assignee:
H. B. Fuller Company - Saint Paul MN
International Classification:
A47L 1130
Abstract:
An automatic self-propelled carpet cleaning machine comprises a body movably mounted by a drive wheel. The body is powered by a drive motor which may be selctively connectable either to an AC power source located separately from the body or to a DC power source contained in the body. In addition, the body includes a first storage chamber for receiving fresh cleaning solution therein and a second storage chamber for receiving spent cleaning solution therein. The first and second storage chambers are provided by a flexible membrane which divides an enclosed cavity into two parts. A scrubbing means is also carried by the body in back of the drive wheel on the body. The scrubbing means includes means for applying the fresh cleaning solution to the carpet, a brush roller for agitating the carpet fibers contacted by the cleaning solution to remove foreign material therefrom, and a vacuum shoe for removing the spent cleaning solution from the carpet and placing that solution in the second storage chamber.
