Michael L Hatton

8016044, Sep 13, 2011

Oct 29, 2009

12/608598

Gaylen J. Kromminga - Morton IL, US
Timothy R. Blunier - Danvers IL, US
Michael C. Hatton - Washington IL, US
Scott Faust - Philo IL, US

CNH America LLC - New Holland PA

A01B 5/00

172178, 172133, 172176, 172196, 172582

In an embodiment, an agricultural implement includes at least a first row of ground engaging tools, each of the tools spaced a first distance apart from one another, and a second row of ground engaging tools disposed behind the first row of ground engaging tools, each of the second row of ground engaging tools spaced a second distance apart from one another. The implement also includes a row of soil shaping disks disposed behind the second row of ground engaging tools, wherein a spacing between each of the soil shaping disks is not uniform and corresponds to whether the spacing is behind the first row of ground engaging disks or behind the second row of ground engaging disks.

D646699, Oct 11, 2011

Mar 30, 2011

29/388564

Dean A. Knobloch - Goodfield IL, US
Michael C. Hatton - Washington IL, US

CNH America LLC - New Holland PA

1503

D15 27

20120247378, Oct 4, 2012

Mar 30, 2011

13/075850

Dean A. Knobloch - Goodfield IL, US
Michael C. Hatton - Washington IL, US
Matthew R. Sudbrink - Peoria IL, US

A01B 73/04
A01C 23/00
A01C 15/00
A01B 73/02

111120, 172311

A fertilizer applicator of increased operating width, e.g., sixty (60) or sixty-five (65) feet, has a carrier frame and a pair of wing sections pivotally mounted to opposite ends of the carrier frame. The wing sections include an inner wing member and an outer wing member. Each wing section includes an actuator for folding/unfolding a respective outer wing member relative to a respective inner wing member. The inner wing member includes a frame member defining an elongated cavity, and the actuator is positioned within the elongated cavity. This allows the actuator to effectively fold/unfold the outer wing member relative to the inner wing member without the physical structure of the actuator impeding movement of the outer wing member thereby allowing the outer wing member to pivot upland to a position against the inner wing member.

D623669, Sep 14, 2010

Jan 14, 2010

29/353784

Gaylen James Kromminga - Morton IL, US
Timothy Richard Blunier - Danvers IL, US
Michael C Hatton - Washington IL, US
Scott Robert Faust - Philo IL, US

CNH America LLC - New Holland PA

1503

D15 27

20180077851, Mar 22, 2018

Sep 16, 2016

15/267958

- New Holland PA, US
Michael C. Hatton - Washington IL, US

CNH Industrial America LLC - New Holland PA

A01B 76/00
A01B 35/32
G01S 15/93
G01S 17/93

An obstacle warning system having sensors solely positioned adjacent the lateral extremities of an implement towed by a tractor for determining the presence of an object within a given distance. An alarm generator positioned within an operator cab for the tractor provides a visual or audible signal indicating the presence of an obstacle in the forward path of the lateral extremities of the implement.
