Kevin F Baron

6796210, Sep 28, 2004

Jan 14, 2002

10/043923

Kevin F. Baron - Newbury Park CA, 91321

B26D 112

83676, 451526, 451527, 451528, 451541, 125 1301, 125 15, 403 2

A cutting disc core for a circular shaped saw blade which has a circular shaped body which has a center hole and a circular peripheral edge upon which is to be mounted a plurality of spaced apart cutting segments that is to perform the cutting of the saw blade. Surrounding the center hole and formed within the body are a plurality of slits with there being a solid tab that is integrally connected to the body located between each directly adjacent pair of slits. The tab constitutes a frangible seal with the circular ring or bushing which is formed about the center hole to be removable by being forcibly physically separated from the body.

6890132, May 10, 2005

Jul 21, 2003

10/624355

Kevin F. Baron - Thousand Oaks CA, US
Kraig M. Baron - Thousand Oaks CA, US
Leon D. Jones - Oxnard CA, US

Western Saw Corporation - Oxnard

B23B051/04

408204, 408226

A bolt on drive assembly for a core drill which utilizes a spoked reinforcer mounted between a pair of discs. The discs are removably mounted on the tube by bolt fasteners. A drive connection is removably mounted and centrally located on a outer disc of the pair of discs. The drive connection is adapted to connect with a drive shaft to cause rotation of the tube.

8347873, Jan 8, 2013

Jul 6, 2009

12/459696

Anthony Baratta - Oak Park CA, US
Kevin Baron - Camarillo CA, US
Kraig Baron - Dos Vientos Ranch CA, US

Western Saw - Oxnard CA

B28D 1/04

125 15, 83676, 125 1301, 451449

A heat reducing slot that is part of a saw blade that includes tips that will house carbide or other tips that are to be attached through a torch or induction. Heat reducing slots repeat for each tip on the perimeter of a blade that will be treated with high heat. For each tip, there is a general area defined near the seat and groove of the tip. In this general area a slot is inserted that has the effect of reducing the amount of heat needed to be applied to the blade for the attachment of carbide or other tips.

20030056633, Mar 27, 2003

Sep 26, 2001

09/964926

Kevin Baron - Newbury Park CA, US
Kraig Mitchell Baron - Oak Park CA, US
Leon Jones - Oxnard CA, US
Scott Eyler - Ventura CA, US

B26D007/27
B23D057/00

083/665000, 083/835000

A cutting disc core which has a circular shaped body which has a center hole and a circular peripheral edge. Formed within the body and located spaced from the center hole and also the peripheral edge are a series of scroll shaped slits each of which has a longitudinal axis that is displaced at an acute angle relative to a radius line which passes through the slit. Each of the slits may be filled with a filler with this filler comprising an epoxy resin impregnated with aluminum powder. Each of the slits are of scroll shape.

20100018377, Jan 28, 2010

May 12, 2009

12/454149

Kevin Baron - Oxnard CA, US

B23D 61/02

83835, 8369851, 83663

A cutting disc core for a circular shaped saw blade which has a circular shaped body which has a center hole and a circular peripheral edge upon which is to be mounted a plurality of spaced apart cutting segments that is to perform the cutting of the saw blade. Surrounding the center hole and formed within the body is a first plurality of slits with there being a solid tab that is integrally connected to the body located between each directly adjacent pair of slits defining a second diameter larger than the center hole. Also included is a second plurality of slits with there being a solid tab that is integrally connected to the body located between each directly adjacent pair of slits defining a third diameter larger than both the center hole and the second diameter defined by the first plurality of slits.

20100107845, May 6, 2010

Nov 4, 2008

12/290945

Kevin Baron - Oxnard CA, US

B26D 7/26
B23D 61/02

83676, 8369841, 83701

A cutting disc core for a circular shaped saw blade which has a circular shaped body which has a center hole and a circular peripheral edge upon which is to be mounted a plurality of spaced apart cutting segments that is to perform the cutting of the saw blade. Surrounding the center hole and formed within the body of the blade is a cut out of a five-sided shape that can be described as a square with rounded corners and with one corner sliced at an angle to leave a fifth side with sharply defined edges. On one or more sides of the five-sided shaped cut out is found one or more pair of radially extending members that together form a break in the continuous shape of the five sided “square” with there being a solid tab that is integrally connected to the body located between each pair of radially extending members. The tab constitutes a frangible seal with the five-sided shape which is formed about the center hole to be removable by being forcibly physically separated from the body.

20100199964, Aug 12, 2010

Feb 10, 2009

12/378133

Kevin Baron - Oxnard CA, US

B28D 1/04
B26D 1/14

125 15, 83676

In a cutting disc which has a plurality of radial slots connecting with the peripheral edge of the disc wherein each radial slot curves to one side wherein the slot has a concave shape relative to the peripheral edge of the disc.

44623828, Jul 31, 1984

Jun 30, 1983

6/509291

Frank C. Baron - Hidden Hills CA
Kevin F. Baron - Hidden Hills CA
Kraig M. Baron - Hidden Hills CA

B24D 506

125 15

Slotted saw blades are shown with wide slots in which hardface inserts extend below the bottoms of the slots and interlock with the core, extend above the periphery of the core, and extend at a negative hook angle for the direction of core rotation. In various embodiments, the inserts, which are bonded to the core, include elements that are integral portions of the cutting segments, elements arranged in each slot so that one is at the negative hook angle for one direction of core rotation and the other is at the negative hook angle for the opposite direction of core rotation, and wedge shaped elements.
