Keith F Stone

6353149, Mar 5, 2002

Apr 8, 1999

09/287986

Keith Joseph Stone - Fairfield OH

The Procter Gamble Company - Cincinnati OH

A61F 1315

604372, 604367, 604375, 604378, 428 98, 428131

Disclosed are fast blooming surfactants that are suitable for inclusion in film compositions that will subsequently treated with a low surface energy material to create a surface energy gradient between the underlying polymeric structure of the film and spaced apart microscopic depositions of the low surface energy material. The surfactants have a permeation rate of less than 240 hours, a surface tension in an aqueous solution at a concentration that is greater than the critical micelle concentration that lies between the critical surface tension of the underlying polymeric structure of the web material and the critical surface tension of the low surface energy depositions; and an HLB between about 6 and about 16. Preferred surfactants also have a weight loss on heating to 250Â C. that is less than about 20%.

6852475, Feb 8, 2005

Mar 14, 2003

10/388864

Keith Joseph Stone - Fairfield OH, US
Timothy Jay Horton - Cincinnati OH, US

The Procter & Gamble Company - Cincinnati OH

B29D007/00
G03C005/58

430320, 430322, 430394, 264132, 264136, 264233, 428131, 428137

A method for making a forming structure. The method comprises the steps of applying a coating of a liquid photosensitive resin to a foraminous element and juxtaposing thereto a first mask comprising both opaque and transparent regions. The photosensitive resin is exposed to light having an activating wavelength to induce partial curing of the photosensitive resin in those regions which are in register with the transparent regions of the first mask. After removal of uncured resin, the process is repeated with a second mask. After removal again of uncured resin, the foraminous element and partially cured resin is immersed in an oxygen-free environment and exposed to light having an activating wavelength to filly cure the partially cured resin to form an apertured forming structure having a plurality of protrusions thereon.

7201853, Apr 10, 2007

Mar 12, 2004

10/799248

Brian Francis Gray - Wyoming OH, US
Keith Joseph Stone - Fairfield OH, US

The Procter & Gamble Company - Cincinnati OH

B44C 1/22
C03C 15/00
C03C 25/68
C23F 1/00
C25C 3/00

216103, 216 9, 156 66

A method for making a forming structure for use in an apparatus for making formed polymeric film. The method comprises a multiple step process of applying a photoresist polymer to a metal base sheet, curing the polymer, acid etching the portions of the metal base sheet not covered by cured polymer to form a protrusion having an upper surface and a side wall (or walls), washing the base sheet with caustic and repeating the process as necessary, each time covering the upper surface and side wall of the protrusion with cured polymer.

7303861, Dec 4, 2007

Mar 28, 2003

10/402396

Brian Francis Gray - Cincinnati OH, US
Keith Joseph Stone - Fairfield OH, US
Sarah Beth Gross - Harrison OH, US
Julie Ann O'Neil - Milan IN, US
Timothy Paul Fiedeldey - Hamilton OH, US

The Procter & Gamble Company - Cincinnati OH

G03F 7/26

430322, 430394

A method for making a forming structure having columnar protrusions extending therefrom comprising the steps of exposing a liquid photosensitive resin to light having an activating wavelength thereby inducing partial curing of the photosensitive resin to form a monolithic slab of partially-cured photosensitive resin; and, including the step of inducing partial curing of a plurality of protrusions on the monolithic slab such that they are joined to and integral with the monolithic slab. The method can further comprise the step of laser etching a plurality of apertures through the forming structure.

7402723, Jul 22, 2008

Dec 20, 2002

10/324366

Keith Joseph Stone - Fairfield OH, US
Brian Francis Gray - Cincinnati OH, US
Norman Scott Broyles - Hamilton OH, US
Dimitris Ioannis Collias - Mason OH, US
Yann-Per Lee - Vernon Hills IL, US

The Procter & Gamble Company - Cincinnati OH

A61F 13/15
B32B 3/10
B32B 5/14

604378, 604370, 604380, 604383, 428131, 428134, 428136, 428138, 428170, 428171

A polymeric web exhibiting a soft and silky tactile impression on at least one side thereof is disclosed. The silky feeling side of the web exhibits a pattern of discrete hair-like fibrils, each of the hair-like fibrils being a protruded extension of the web surface and having a side wall defining an open proximal portion and a closed distal portion. The hair-like fibrils exhibit a maximum lateral cross-sectional diameter of between 2 and 5 mils, and an aspect ratio from 1 to 3. Methods and apparatus for making the polymeric web utilize a three-dimensional forming structure having a plurality of protrusions being generally columnar forms having an average aspect ratio of at least about 1.

7521588, Apr 21, 2009

May 12, 2005

11/127472

Keith Joseph Stone - Fairfield OH, US
Brian Francis Gray - Cincinnati OH, US
Norman Scott Broyles - Hamilton OH, US
Dimitris Ioannis Collias - Mason OH, US
Yann-Per Lee - Vernon Hills IL, US

The Procter & Gamble Company - Cincinnati OH

A61F 13/15
B32B 3/10
B32B 5/14

604378, 604370, 604380, 604383, 428131, 428134, 428136, 428138, 428170, 428171

A polymeric web exhibiting a soft and silky tactile impression on at least one side thereof is disclosed. The silky feeling side of the web exhibits a pattern of discrete hair-like fibrils, each of the hair-like fibrils being a protruded extension of the web surface and having a side wall defining an open proximal portion and a closed distal portion. The hair-like fibrils exhibit a maximum lateral cross-sectional diameter of between 2 and 5 mils, and an aspect ratio from 1 to 3. Methods and apparatus for making the polymeric web utilize a three-dimensional forming structure having a plurality of protrusions being generally columnar forms having an average aspect ratio of at least about 1.

7655176, Feb 2, 2010

Dec 20, 2002

10/325323

Keith Joseph Stone - Fairfield OH, US
Brian Francis Gray - Cincinnati OH, US
Julie Ann O'Neil - Milan IN, US

The Procter & Gamble Company - Cincinnati OH

B29C 59/04
B29C 39/14
B29C 71/02
B28B 1/48

264504, 264544, 264547, 264548, 264570, 264299, 264346, 264442, 264458, 264900, 425290, 4253871

A polymeric web exhibiting a soft and silky tactile impression on at least one side thereof is disclosed. The silky feeling side of the web exhibits a pattern of discrete hair-like fibrils, each of the hair-like fibrils being a protruded extension of the web surface and having a side wall defining an open proximal portion and a closed distal portion. The hair-like fibrils exhibit a maximum lateral cross-sectional diameter of between 2 and 5 mils, and an aspect ratio from 1 to 3. Methods and apparatus for making the polymeric web utilize a three-dimensional forming structure having a plurality of protrusions being generally columnar forms having an average aspect ratio of at least about 1.

7713683, May 11, 2010

Aug 16, 2007

11/893426

Brian Francis Gray - Cincinnati OH, US
Keith Joseph Stone - Fairfield OH, US
Sarah Beth Gross - Harrison OH, US
Julie Ann O'Neil - Milan IN, US
Timothy Paul Fiedeldey - Hamilton OH, US

The Procter & Gamble Company - Cincinnati OH

G03F 7/26

430322, 430330

A method for making a forming structure having columnar protrusions extending therefrom comprising the steps of exposing a liquid photosensitive resin to light having an activating wavelength thereby inducing partial curing of the photosensitive resin to form a monolithic slab of partially-cured photosensitive resin; and, including the step of inducing partial curing of a plurality of protrusions on the monolithic slab such that they are joined to and integral with the monolithic slab. The method can further comprise the step of laser etching a plurality of apertures through the forming structure.
