John Dale Mcclure

6927370, Aug 9, 2005

Nov 21, 2003

10/719583

John L. McClure - Rochester Hills MI, US
Suresh C. Ramalingam - Troy MI, US
James P. Lezotte - Oxford MI, US

DaimlerChrysler Corporation - Auburn Hills MI

B23K013/01
H05B006/10

219603, 219633, 219659

A hemming machine for joining an inner sheet metal panel with an outer sheet metal panel comprising: a hemming tool containing an electromagnetic coil positioned to electromagnetically crimp and/or weld the outer sheet metal panel to the inner sheet metal panel, where a backing die positioned outside the inner metallic sheet and the outer metallic sheet opposite the electromagnetic coil.

D2516560, Apr 24, 1979

Aug 26, 1977

5/828162

John F. McClure - Rochester MI

D0899

D 8359

43287034, May 11, 1982

Feb 14, 1980

6/121358

John W. McClure - Houston TX
George S. Hudson - Hamden CT

Avco Corporation - Stratford CT

G01L 513

731174

A test stand for measuring the thrust produced by a jet engine includes a base and a floating frame having the engine connected thereto, with the floating frame being disposed in spaced, parallel relationship to said base. The base and floating frame are interconnected by a plurality of elongated support flexures, each of which is provided with a first and second elongated generally planar webs, disposed in axial alignment and with the plane of the first web being orthogonal to the plane of the second web. The flexures are disposed such that the plane of the fist web is perpendicular to the logitudinal axis of the jet engine. In operation, the thrust of the jet engine causes movement of the floating frame relative to the base thereby resulting in a corresponding bending of the flexure, with the bending being localized in the first web to facilitate its measurement. A control circuit is provided which includes a plurality of transducers that are bonded to the flat surface portion of the first web. The transducers are interconnected in a Wheatstone's bridge arrangement to produce an accurate measurement of thrust.

48319023, May 23, 1989

Apr 11, 1988

7/179961

John H. McClure - Hillsboro OH

B25B 1350

81 532

A tool and method for extracting a broken bolt shank, stud or other threaded member from a mating tapped hole is described wherein a segment of threaded rod having a plurality of off-axis longitudinal holes therethrough is threaded against or otherwise held in axial abutting relationship with the end of the broken bolt shank to be removed, alignment holes are drilled into the shank using the threaded rod segment as a guide, an alignment pin is inserted through each alignment hole to pin the threaded rod segment to the shank, and the shank and threaded rod segment are simultaneously backed out of the tapped hole by applying torque to the segment using one or a pair of nuts locked on the threaded rod segment or using a screwdriver wrench engaging one end of the threaded rod segment.

59339993, Aug 10, 1999

Aug 17, 1998

9/135425

John H. McClure - Hillsboro OH
Mary Anne McClure - Hillsboro OH

F41A 2730

42 94

A gun rest is described that includes an arcuate elongate rocker member having a first substantially U-shaped bracket at one end thereof for supporting the barrel of the firearm and a second substantially U-shaped bracket at the other end for supporting the firearm forward of the trigger or receiver thereof, the rocker member being pivotally attached to a yoke and rotatably mounted on a vertical support member having structure thereon for attachment to a vehicle or otherwise anchored at a selected other location.

20180327235, Nov 15, 2018

Sep 7, 2017

15/697967

John McClure - Hillsboro OH, US

B66F 3/36
B66F 7/16

A vehicle lift has lift arms pivoted to a central or to side lifts. A handle is pivoted to an extensible, retractable lift arm end and can be manipulated from outside the vehicle periphery to position the lift arm end in a desired alignment with lift points under the vehicle frame.
