Joel C Johnson

6414754, Jul 2, 2002

Mar 8, 2000

09/521233

Joel C. Johnson - Lake Oswego OR

Pacific Scientific Instruments Company - Grants Pass OR

G01N 2100

356338, 356339, 2502222, 372 22

A preferred OPTICAL BLACKâ ionic anodize process of the present invention applies a porous anodic oxide coating to a component part in a standard sulfuric acid anodizing bath (with or without organic additives). A modified alternating electric current is then applied to the porous oxide coating to remove excess anodizing electrolyte and to allow the coloring solution access to the pores. The oxide coating is electrolytically colored in a low pH acid bath containing a tin salt, sulfuric acid, and organic additives. Alternating current carries additional tin salt to the base of the pores where the tin salt is reduced to metallic tin or tin oxide. Others metals or metallic salts could be employed. Component parts treated by the OPTICAL BLACKâ ionic anodize process can be advantageously employed in optical systems, such as particle detectors, to reduce or eliminate stray light.

45589267, Dec 17, 1985

Jan 20, 1983

6/459303

Joel C. Johnson - Lake Oswego OR

Electro Scientific Industries, Inc. - Portland OR

G02F 111

350373

An acousto-optic beam deflector comprises an optically active stress optic medium, such as crystalline quartz, driven by a longitudinal acoustic wave transducer. The deflector is independent of optical polarization, and therefore both polarization components of an input optical beam, such as a laser beam, are scattered with equal efficiencies.

55327710, Jul 2, 1996

Dec 17, 1993

8/169494

Joel C. Johnson - Lake Oswego OR
Robert B. Hill - Portland OR

EDI of Louisiana, Inc. - Baton Rouge LA

A61B 310
G02B 2608

351211

An optical scanner (100) includes a rotating scanner disk (116) that integrates a multifocal Fresnel fixation lens (114), a Fresnel optical scanner (122, 124), and an angular position encoder (140) into a unitary, inherently aligned, compression-molded component. An individual being identified views through the multifocal Fresnel fixation lens an image of a pinhole (108) illuminated by a light source (104). The multifocal lens is centered on the disk and creates multiple in- and out-of-focus images (180, 182, 184, 186) of the pinhole image. The combined image appears to the individual as a set of circular images (190, 192, 194, 196), one of which is in focus. The images appear concentric when the individual is properly aligned with the disk and associated optics. The Fresnel optical scanner receives IR light from the light source and creates an IR scanning beam (126) when the disk is rotated. IR light reflected by the fundus (12) of the individual returns via a reciprocal path, by way of a beam splitter (112), and into a detector (134) to generate image data.

62891073, Sep 11, 2001

May 23, 1996

8/652350

Robert E. Borchers - Lake Oswego OR
Joel C. Johnson - Lake Oswego OR
Eric Thomas Peterson - Portland OR

Nike, Inc. - Beaverton OR

G06K 900

382100

A device and method is provided for quickly and accurately determining the size and shape of a human extremity such as a foot by projecting light around a periphery of the extremity and capturing an image of the illuminated foot through a transparent plate. Various embodiments contemplate using light having a wavelength in the near-infrared range to reduce contrast problems caused by dyes used in socks and skin tone problems created by highly pigmented individuals. An image of the foot is digitized and stored in a computer memory in both an illuminated state and a non-illuminated state, and the two images are subtracted. Additional image processing steps on the subtracted image result in various measurement quantities such as foot length, width, arch length, heel width, and arch height.

51212455, Jun 9, 1992

Apr 6, 1989

7/334298

Joel C. Johnson - Lake Oswego OR

Electro Scientific Industries, Inc. - Portland OR

G02F 111
H01S 311
H01S 3117
H01S 313

359285

The present invention is a laser system that includes an acousto-optic device (24B) having an optical medium (40B) that maintains a substantially uniform index of refraction even when subjected to nonuniform thermal or mechanical stress. The acousto-optic device provides substantially distortion-free polarized output light that can be directed accurately to strike an intended target.

52529126, Oct 12, 1993

Jun 6, 1991

7/711921

William E. Merritt - Portland OR
Joel Johnson - Lake Oswego OR

G01R 3102

324 72

A detector for use on board an aircraft traveling along a path of movement to detect a power line comprises an antenna for sensing the electric field associated with the power line and producing an electric field signal, and a signal processor for receiving the electric field signal and generating a time-to-impact signal representative of the time for the aircraft to reach the power line if it continues on its path of movement. Sensors are used to determine the direction of the power line.

50576640, Oct 15, 1991

Oct 20, 1989

7/424802

Joel C. Johnson - Lake Oswego OR
Ho W. Lo - Portland OR
David Rowley - Aloha OR
Terri J. Irland - Aloha OR

Electro Scientific Industries, Inc. - Portland OR

B23K 2600

21912169

A diode-pumped laser system (10) incorporates a polarization state control device (12) that provides a trim profile (84) having minimal striations (64) on a target material (42). The striations run generally parallel to the polarization direction of laser output light beam (L) and are diminished whenever the polarization direction is parallel to the laser trimming direction. The striations are substantially eliminated by circularly or randomly polarizing the laser output light beam.

49309013, Jun 5, 1990

May 26, 1989

7/357979

Joel C. Johnson - Lake Oswego OR
Richard S. Harris - Portland OR

Electro Scientific Industries, Inc. - Portland OR

H01S 310

372 26

A laser system operable in both a lead bonding mode and a lead severing mode. When in the lead bonding mode, the light-amplifying medium (38) of the laser is optically pumped by a lamp (45) to produce laser pulses within the laser cavity (36). The power supply (56) is rapidly switched to provide the bonding pulses (L. sub. b) at a high repetition rate. A Q-switch (46) is disposed within the cavity (36) to shape the laser output pulses (L. sub. b) with a leading power spike (S. sub. b) that is suitable for reducing the reflectivity of the lead (20) surface, thereby facilitating maximum absorption of the laser energy for the bonding operation. When in the severing mode, the light-amplifying medium (38) is continuously pumped and the Q-switch (46) is repetitively switched at a rate high enough to generate laser pulses (L. sub. s) suitable for severing the leads (20) without heating adjacent portions of the leads (20).
