Huy H Luong

6728908, Apr 27, 2004

Nov 20, 2000

09/717800

Ryan Fukuhara - Torrance CA
Leonard Day - Pasadena CA
Huy H. Luong - San Marino CA
Robert Rasmussen - Monrovia CA
Savio N. Chau - Hacienda Heights CA

California Institute of Technology - Pasadena CA

G06F 1100

714 48, 714 43, 716 4

In an embodiment, a bus controller for connecting a device to an Inter-Integrated Circuit (I2C) bus includes fault tolerance features. The I2C bus controller may support fail silent, cyclic redundancy check (CRC), and byte count check operations. The I2C bus controller may include a control unit connected to an I2C core module having a base address. The I2C bus controller may also include a second I2C core module having a base address plus one (BP ). The I2C bus controller may also include a mute timer that countdowns a mute timeout period. This mute timer may be reset upon receiving a fail silent test message sent by a master on the I2C bus in slave mode, or, in the master mode, from itself through the BP I2C core module. If the mute timeout period expires, the control unit may disable the I2C bus controller from transmitting on the I2C bus. The control unit may format CRC values and byte count values into messages, and include a byte counter to compare actual bytes received to the expected byte count indicated by a received byte count value.

57905673, Aug 4, 1998

Aug 28, 1995

8/519786

Gary S. Bolotin - Moneovia CA
James A. Donaldson - Glendale CA
Huy H. Luong - Alhambra CA
Steven H. Wood - Los Angeles CA

California Institute of Technology - Pasadena CA

H03M 1300
H04B 7204
H04B 7185
H04J 324

371 3701

An uplink controlling assembly speeds data processing using a special parallel codeblock technique. A correct start sequence initiates processing of a frame. Two possible start sequences can be used; and the one which is used determines whether data polarity is inverted or non-inverted. Processing continues until uncorrectable errors are found. The frame ends by intentionally sending a block with an uncorrectable error. Each of the codeblocks in the frame has a channel ID. Each channel ID can be separately processed in parallel. This obviates the problem of waiting for error correction processing. If that channel number is zero, however, it indicates that the frame of data represents a critical command only. That data is handled in a special way, independent of the software. Otherwise, the processed data further handled using special double buffering techniques to avoid problems from overrun.

57905681, Aug 4, 1998

Jan 31, 1996

8/594728

Huy H. Luong - Alhambra CA
James A. Donaldson - Glendale CA
Steven H. Wood - Los Angeles CA

California Institute of Technology - Pasadena CA

G03M 1300

371 371

Apparatus and method for providing downlink frames to be transmitted from a spacecraft to a ground station. Each downlink frame includes a synchronization pattern and a transfer frame. The apparatus may comprise a monolithic Reed-Solomon downlink (RSDL) encoding chip coupled to data buffers for storing transfer frames. The RSKL chip includes a timing device, a bus interface, a timing and control unit, a synchronization pattern unit, and a Reed-Solomon encoding unit, and a bus arbiter.
