Dwight D Hill

45424560, Sep 17, 1985

Apr 28, 1982

6/372482

Dwight D. Hill - Holmdel NJ

AT&T Bell Laboratories - Murray Hill NJ

G06F 702

364200

Disclosed is a method and an apparatus for range checking a value in a programmable system. An instruction prefix LDRNG enables the checking of a value against one or both limits of a range of values. The value is calculated as part of the execution of a primary instruction which is any suitable instruction, such as ADD, MOVE, STORE, etc. , that directly follows the prefix. During the execution of the primary instruction the range check is performed, and an exception is taken without completing execution of the primary instruction if the value does not lie within the range.

52552217, Oct 19, 1993

Apr 2, 1991

7/679370

Dwight D. Hill - Holmdel NJ

AT&T Bell Laboratories - Murray Hill NJ

G11C 700

36518908

A field configurable function element offers multi-function use of memory cells by organizing the cells in memory banks and by providing internal configurable interconnections of the memory banks. A versatile logic function configuration is obtained by storing the truth table of the desired logic functions in the memory cells. An arithmetic functions configuration is obtained by internally interconnecting the memory cells. A read/write memory function configuration is obtained by adding write address decoding, write enablement capability and input data leads. The configuration permits a parallel writing and reading of the memory cells, thereby effectuating a two-port memory operation. An added set of latches connected to the configurable function element and a configurable routing network connected to the inputs of the configurable function element, to the output of the configurable function element and to the output of the latches, form a powerful device that can be easily configured to any one of the three primary modes (logic, arithmetic and memory). A generalized routing fabric coupled to the routing network provides for configurable connections to other configurable function devices.

52395103, Aug 24, 1993

Nov 25, 1991

7/797648

Dwight D. Hill - Holmdel NJ

AT&T Bell Laboratories - Murray Hill NJ

G11C 1100

365226
