David P Lynd

D616118, May 18, 2010

May 18, 2009

29/315015

James Thomas - Tierra Verde FL, US
Gary Gatesman - Indian Rocks Beach FL, US
David Lynd - Seminole FL, US
Jim Mosier - St. Petersburg FL, US

ElectraLED Inc. - Largo FL

2604

D26 2

D624214, Sep 21, 2010

May 18, 2009

29/315020

James Thomas - Tierra Verde FL, US
Gary Gatesman - Indian Rocks Beach FL, US
David Lynd - Seminole FL, US
Jim Mosier - St. Petersburg FL, US

ElectraLED Inc. - Largo FL

2604

D26 2

8235539, Aug 7, 2012

Jun 25, 2007

11/821793

James Thomas - Tierra Verde FL, US
David Lynd - Seminole FL, US
Gary Gatesman - Rocks Bch. FL, US
Jim Mosier - St. Petersburg FL, US
Bryan T. Warner - St. Pete FL, US

ElectraLED, Inc. - Largo FL

F21V 33/00

362 92, 362 93, 362 94

The invention provides an elongated lighting fixture with multiple light emitting diodes (LEDs) arrayed in two groups that are angled to each other. The fixture provides an extremely broad light emitting angle and includes an elongated housing having a pair of side walls with at least one fin to dissipate heat. Each side wall has a support member extending upward at angle from the side wall, wherein the side walls terminate at a central wall. A generally transparent cover is connected to the housing and extends between opposed ends of the housing. A first elongated fastener and a second elongated fastener are utilized to mount a first group of LEDs and a second group of LEDs to the first support member and the second support member, respectively. First and second interconnection board assemblies are affixed to respective support members beneath the group of LEDs by the first and second fasteners. When the first and second interconnection board assemblies are energized by an internal power source, current travels from each interconnection assembly through the fasteners to each group of LEDs for illumination.

8235555, Aug 7, 2012

May 18, 2009

12/454436

James Thomas - Tierra Verde FL, US
Gary Gatesman - Indian Rocks Beach FL, US
David Lynd - Seminole FL, US
Jim Mosier - St. Petersburg FL, US
Bryan T. Warner - St. Petersburg FL, US

ElectraLED, Inc. - Largo FL

F21V 29/00

362294

The invention provides a multi-use light fixture that includes a light engine, a rugged housing, and an external power supply removeably embedded within an optional external enclosure. The light fixture includes several novel heat management features designed to reduce the risk of failure and thereby increase the reliability of the light fixture. The light engine includes groups of light modules, each having a light emitting diode (LED) and a zener diode. The housing includes an internal gap defined between the a circuit board and the housing. The housing also includes an arrangement of external fins and vents that dissipate heat generated by the light engine. The lens cover includes a plurality of inlets to supply ambient air into the fixture. During operation, heat is generated by the light modules, namely the LEDs, and then is transferred along a first flow path through a main body portion of the housing and the fins for dissipation to ambient and a second air flow path whereby ambient air flows through the light engine to increase the performance and efficiency of the light engine.

20080310162, Dec 18, 2008

Jun 13, 2007

11/818216

James Thomas - Tierra Verde FL, US
David Lynd - Seminole FL, US
Gary Gatesman - Indian Rocks Bch FL, US
Jim Mosier - St. Petersburg FL, US
Bryan T. Warner - St. Pete FL, US

F21V 21/005

362249

The invention provides a light fixture that includes a light engine, a rugged housing, and an internal power module that is thermally isolated. The light fixture includes several novel heat management features designed to thermally isolate the power supply in order to reduce the risk of failure and thereby increase the reliability of the light fixture. The light engine includes groups of light modules, each having a light emitting diode (LED) and a zener diode. The power module resides within a rear receptacle of the housing and includes a power supply, a box, and a cover that enclose the power supply. The housing also includes an arrangement of external fins that dissipate heat generated by the light engine. During operation, heat is generated by the light modules, namely the LEDs, and then is transferred along a flow path through a main body portion of the housing and the fins for dissipation to ambient without negatively impacting the power supply.

20120293996, Nov 22, 2012

Mar 21, 2012

13/426212

James Thomas - Tierra Verde FL, US
Gary Gatesman - Indian Rocks Beach FL, US
James Mosier - St. Petersburg FL, US
David Lynd - Seminole FL, US
Brandon Scott Abril - Largo FL, US

F21V 21/00
F21V 5/04
F21V 29/00

362235, 36224902

An LED lighting element is configured to receive electrical power from a fluorescent lighting fixture ballast. The LED lighting element includes a base and a light engine coupled to the base. The light engine includes at least one LED. An end cap is coupled to the base and defines an enclosed chamber. A converter module is housed within the enclosed chamber and is electrically coupled to the light engine. The converter module is configured to convert AC power from the fluorescent lighting fixture ballast to DC power for powering the at least one LED.

20120294000, Nov 22, 2012

Aug 6, 2012

13/567488

James Thomas - Tierra Verde FL, US
David Lynd - Seminole FL, US
Gary Gatesman - Indian Rocks Beach FL, US
Jim Mosier - St. Petersburg FL, US
Bryan T. Warner - St. Petersburg FL, US

ElectraLED Inc. - Largo FL

F21V 29/00
F21V 5/04

362235, 36224902

An LED light fixture is provided and includes a light engine assembly having a plurality of LED light modules mounted to a printed circuit board. The light engine assembly has a substantially circular periphery. A substantially cylindrical main body portion surrounds the light engine assembly and is sized to define a substantially annular gap between an inner surface of the main body portion and the periphery of the light engine. A plurality of radially extending and circumferentially arrayed fins are positioned rearward of the light engine assembly, and a thermal pad is coupled to and positioned between a rear surface of the light engine assembly and the plurality of fins for transferring heat away from the light engine assembly. The annular gap at least partially defines an air flow path in communication with spaces between the fins. An LED track lighting fixture including the LED light fixture also is provided.

20120300441, Nov 29, 2012

Jul 13, 2012

13/548430

James Thomas - Tierra Verde FL, US
David Lynd - Seminole FL, US
Gary Gatesman - Indian Rocks Beach FL, US
Jim Mosier - St. Petersburg FL, US
Bryan T. Warner - St. Petersburg FL, US

ElectraLED, Inc. - Largo FL

F21S 4/00
F21L 4/02

362184, 362225

The invention provides an elongated lighting fixture with multiple light emitting diodes (LEDs) arrayed in two groups that are angled to each other. The fixture includes an elongated housing having a pair of side walls with at least one fin to dissipate heat. Each side wall has a support member extending upward at angle from the side wall. A generally transparent cover is connected to the housing and extends between opposed ends of the housing. A first group of LEDs and a second group of LEDs are mounted to the first support member and the second support member, respectively. First and second interconnection board assemblies are affixed to respective support members beneath the group of LEDs. When the first and second interconnection board assemblies are energized by an internal power source, current travels from each interconnection assembly through fasteners to each group of LEDs for illumination.
