James E Crum

6918967, Jul 19, 2005

Mar 8, 2001

10/221809

James R. Crum - Ona WV, US
Frances S. Suarez - Huntington WV, US
Sarwan K. Mannan - Barboursville WV, US
Vernon W. Hartmann - Culloden WV, US

Huntington Alloys Corporation - Huntington WV

C22C038/38

148327, 420 44, 420 45, 420 46

An austenitic alloy having improved ductility/processability and improved pitting and crevice corrosion resistance comprising, in % by weight, about: 25-30% Ni; 19-23% Cr; 6-8% Mo; 0. 3-0. 5% N; 0. 5% Mn; 0-1. 5% Cu; 0-0. 2% C; 0-1% Al; 0-0. 01% S; 0-1% Ti; 0-1% Si; up to trace amounts of Mg, Ca, and Ce; and balance Fe plus incidental impurities.

7815848, Oct 19, 2010

Apr 23, 2007

11/788931

James Roy Crum - Ona WV, US
Nathan Charles Eisinger - Huntington WV, US
Stephen Mark Gosnay - Ona WV, US
Gaylord Darrell Smith - Huntington WV, US

Huntington Alloys Corporation - Huntington WV

C22C 38/44
C22C 38/50
C22C 30/00

420 53, 4205861, 4205841, 420 66

A corrosion resistant alloy is provided which includes, in percent by weight: (a) 16 to 24% Ni; (b) 18 to 26% Cr; (c) 1. 5 to 3. 5% Mo; (d) 0. 5 to 1. 5% Si; (e) 0. 001 to 1. 5% Nb; (f) 0. 0005 to 0. 5% Zr; (g) 0. 01 to 0. 6% N; (h) 0. 001 to 0. 2% Al; (j) less than 0. 2% Ti; and (k) less than 1% Mn, trace impurities, and the balance Fe. Articles, such as flexible automotive exhaust couplings, including the present alloys are also provided.

49699644, Nov 13, 1990

May 19, 1989

7/354310

James R. Crum - Ona WV
William G. Lipscomb - Barboursville WV
Pasupathy Ganesan - Huntington WV

Inco Alloys International, Inc. - Huntington WV

C22D 1905

148410

A heat treatment of alloy 617 generally including 732. degree. C. -927. degree. C. (1350. degree. F. -1700. degree. F. ) for about one hour. The resultant discontinuous carbide network in the grain boundaries inhibits stress corrosion crack growth in polythionic acid environments.

51206145, Jun 9, 1992

Oct 21, 1988

7/260982

Edward L. Hibner - Ona WV
Ralph W. Ross - Huntington WV
James R. Crum - Ona WV

Inco Alloys International, Inc. - Huntington WV

B32B 1501
C22C 1905

428679

A nickel-chromium-molybdenum-niobium alloy affords high resistance to aggressive corrosives, including chlorides which cause crevice corrosion and oxidizing acids which promote intergranular corrosion, the alloy also being readily weldable and possessing structural stability at very low as well as elevated temperatures. The alloy consists essentially of, (by weight), 19-23% Cr, 12-15% Mo, 2. 25-4% W, 0. 65-2% Nb, 2-8% Fe, balance Ni.

50191845, May 28, 1991

Jan 26, 1990

7/467810

James R. Crum - Ona WV
Jon M. Poole - Barboursville WV
Edward L. Hibner - Ona WV

Inco Alloys International, Inc. - Huntington WV

C22F 110

148 13

A homogenizaton heat treatment for enhancing crevice and pitting corrosion resistance minimizes the formation of Mu phase in nickel-base alloys of high combined percentages of chromium, e. g. , 19 to 23% and molybdenum, e. g. , 14 to 17%, particularly together with tungsten. Also described is an advantageous alloy composition containing less than 2. 5% iron, low carbon and a titanium to carbon ratio greater than 1 which is particularly adapted to be effectively treated by the homogenization heat treatment.

40509281, Sep 27, 1977

Feb 17, 1976

5/658227

James Roy Crum - Ona WV

The International Nickel Company, Inc. - New York NY

C22C 3002
C22C 3806
C22C 3842

75124

Iron-based alloy composition containing special proportions of nickel, chromium, aluminum, copper and carbon provides good corrosion-resistance characteristics for service in caustic media, e. g. , sodium hydroxide, chloride media, e. g. , magnesium chloride, caustic-chloride media, e. g. , sodium hydroxide-sodium chloride mixtures, and also when exposed to some acid media, e. g. , nitric acid. Special utility particularly includes resistance to stress-corrosion-cracking in hot caustic and chloride media. Alloy has good workability for production of wrought products such as plate, bar and sheet and is also suitable for making corrosion-resistant castings and welded structures, e. g. , chemical plant equipment.

48162175, Mar 28, 1989

Apr 21, 1986

6/854340

Thomas H. Bassford - Huntington WV
James R. Crum - Ona WV

Inco Alloys International, Inc. - Huntington WV

C22C 3002
C22C 3842

420582

An austenitic, age-hardenable nickel-iron-chromium alloy exhibiting high-strength, good corrosion and polythionic acid resistance and having a low work hardening rate. The economic alloy is useful for industrial vessels such as heat exchangers, chemical and petrochemical equipment and, more particularly, tubes. The alloy includes about 25-29. 5% nickel, about 14. 5-17. 5% chromium, about 2-3. 5% molybdenum, about 2-5. 5% copper, about 1-5% titanium plus aluminum, up to about 1. 5% manganese, up to about 0. 1% cerium, and the balance mostly iron.

58273778, Oct 27, 1998

Oct 31, 1996

8/757405

James Roy Crum - Ona WV
Gaylord Darrell Smith - Huntington WV
Vernon William Hartmann - Huntington WV
William Lawrence Mankins - Huntington WV

INCO Alloys International, Inc. - Huntington WV

C22C 3000

148442

A nickel-base alloy having characteristics midway between selected stainless steels and INCONEL. RTM. alloy 625LCF. RTM. Flexible and particularly useful for exhaust system bellows, wires and braids, the alloy includes about 24-42% nickel, about 18-28% chromium, 1. 5-6% molybdenum, 0. 2-1 % titanium, up to 1% aluminum, the balance iron, and up to about 1. 4% silicon. The alloy demonstrates a novel characteristic of becoming stronger and more ductile during contemplated service temperatures of about 800. degree. -1400. degree. F. (427. degree. C. -760. degree. C. ).
